Gambar hanya untuk referensi, lihat spesifikasi produk
G2RL-1A-E2-CV-HA DC5
| Produsen: | Omron Electronics Inc-EMC Div |
|---|---|
| Kategori Produk: | Power Relays, Over 2 Amps |
| Lembar data: | G2RL-1A-E2-CV-HA DC5 |
| Deskripsi: | RELAY GEN PURPOSE SPST 23A 5V |
| Status RoHS: | Sesuai RoHS |
| Atribut | Nilai atribut |
|---|---|
| Produsen | Omron Electronics Inc-EMC Div |
| Kategori Produk | Power Relays, Over 2 Amps |
| Seri | G2RL |
| Fitur | - |
| Coil jenis | Non Latching |
| Kemasan | Tray |
| Tipe relay | General Purpose |
| Status bagian | Active |
| Peringkat Seal | Sealed - Flux Protection |
| Arus Coil | 80.0mA |
| Coil tegangan | 5VDC |
| Formulir kontak | SPST-NO (1 Form A) |
| Operasikan waktu | 15ms |
| Waktu rilis | 5ms |
| Jenis pemasangan | Through Hole |
| Coil isolasi | Class F |
| Coil perlawanan | 62.5 Ohms |
| Bahan kontak | Silver Alloy, Cadmium Free |
| Tegangan switching | 250VAC - Max |
| Penghentian gaya | PC Pin |
| Harus operasikan Voltase | 3.75 VDC |
| Voltase rilis harus | 0.5 VDC |
| Suhu operasi | -40°C ~ 105°C |
| Rating kontak (saat ini) | 23A |
Dalam stok 468 pcs
| Harga refrence ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $4.33 | $4.24 | $4.16 |
